Calibrating pen through xinput

So, this is too long, I’m gonna just make a new post for it. When I connect the tablet to a projector, due to change of resolution the pen is not calibrated any more. I’ve tried xinput_calibrator to adjust it, but since it “auto-detect”s misclicks I can’t really get it to work. I tried to turn it off using the option --misclick 0, but that also didn’t work. The option --precalib doesn’t get me anywhere.

Then I found this wiki post from ArchLinux and it does exactly what I need to do, except the numbers are a little off. For a discussion on this problem see the SE post for the initial problem, and this SE post for the exact values.

Here is what I’ve done:

- From `xrandr` I get:

Screen 0: minimum 8 x 8, current 1024 x 768, maximum 32767 x 32767
LVDS1 connected primary 1024x768+0+0 (normal left inverted right x axis y axis) 277mm x 156mm
   1366x768      60.02 +
   1280x720      60.00
   1024x768      60.00*
   1024x576      60.00
   ...

The one with + is maximum resolution my monitor supports and the one with * is the current resolution. So, I conclude

total_width = 1024
touch_area_width = 1366
touch_area_x_offset = (1024 - 1366) /2 = -171

This is probably what I’m doing wrong, because at the end I don’t get exactly what I need, but almost there. - Then I look at the output of xinput list ``

⎡ Virtual core pointer                        id=2    [master pointer  (3)]
⎜   ↳ Virtual core XTEST pointer                  id=4    [slave  pointer  (2)]
⎜   ↳ Logitech M325                               id=9    [slave  pointer  (2)]
**⎜   ↳ Wacom ISDv4 E6 Pen stylus                   id=10    [slave  pointer  (2)]**
**⎜   ↳ Wacom ISDv4 E6 Finger                       id=11    [slave  pointer  (2)]**
⎜   ↳ SynPS/2 Synaptics TouchPad                  id=13    [slave  pointer  (2)]
⎜   ↳ TPPS/2 IBM TrackPoint                       id=14    [slave  pointer  (2)]
**⎜   ↳ Wacom ISDv4 E6 Pen eraser                   id=16    [slave  pointer  (2)]**
⎣ Virtual core keyboard                       id=3    [master keyboard (2)]
    ↳ Virtual core XTEST keyboard                 id=5    [slave  keyboard (3)]
    ↳ Power Button                                id=6    [slave  keyboard (3)]
    ↳ Video Bus                                   id=7    [slave  keyboard (3)]
    ↳ Sleep Button                                id=8    [slave  keyboard (3)]
    ↳ AT Translated Set 2 keyboard                id=12    [slave  keyboard (3)]
    ↳ ThinkPad Extra Buttons                      id=15    [slave  keyboard (3)]

The bold lines are the ones that I need, so the DEVICE NAMEs for me will be "Wacom ISDv4 E6 Pen stylus", "Wacom ISDv4 E6 Finger", and "Wacom ISDv4 E6 Pen eraser". - xinput list-props "device name" | grep Matrix should list the current Coordinate Transformation Matrix. The default is the identity matrix which is listed by rows:

Coordinate Transformation Matrix (138): 1.000000, 0.000000, 0.000000, 0.000000, 1.000000, 0.000000, 0.000000, 0.000000, 1.000000

- The transformation matrix is The matrix is

$\begin{bmatrix} c_0 & 0 & c_1 \ 0 & c_2 & c_3 \ 0 & 0 & 1\end{bmatrix}$You can see that when it’s multiplied by the vector $\begin{bmatrix} x_1 \ x_2 \ 1\end{bmatrix}$ from left it produces $\begin{bmatrix} c_0 x_1 + c_1 \ c_2 x_2 + c_3 \ 1\end{bmatrix}$ which is just a scaling and shift on $x_1$ and $x_2$. - The tutorial says to calculate the matrix as follows:

$c_0$ = touch_area_width / total_width = 1366/1024 = 1.333984375
$c_2$ = touch_area_height / total_height = 768/768 = 1
$c_1$ = touch_area_x_offset / total_width = -171/768 = -0.22265625
$c_3$ = touch_area_y_offset / total_height = 0/768 = 0

The reason $c_2 = 1$ and $c_3 = 0$ for me is that in my situation the height is fine, so I only need to scale and shift the width. - All I need to do now is to represent my matrix as an array of rows, that is: c0 0 c1 0 c2 c3 0 0 1 and that for me becomes: 1.333984375 0 -0.22265625 0 1 0 0 0 1 - Then the following command should do the translation for me: xinput set-prop "DEVICE NAME" --type=float "Coordinate Transformation Matrix" 1.333984375 0 -0.22265625 0 1 0 0 0 1 - That almost gets me where I want to be except it’s still a little off. So, I did a little bit of trial and error to get the following numbers and it’s working quite well: xinput set-prop "DEVICE NAME" --type=float "Coordinate Transformation Matrix" 1.345 0 -0.17  0 1 0 0 0 1 - To do: I have to figure out how to find the exact values. - Final command that does it all for me in one line is: xinput set-prop "Wacom ISDv4 E6 Pen stylus" --type=float "Coordinate Transformation Matrix" 1.345 0 -0.17  0 1 0 0 0 1 && xinput set-prop "Wacom ISDv4 E6 Finger" --type=float "Coordinate Transformation Matrix" 1.345 0 -0.17  0 1 0 0 0 1 && xinput set-prop "Wacom ISDv4 E6 Pen eraser" --type=float "Coordinate Transformation Matrix" 1.345 0 -0.17  0 1 0 0 0 1 - And finally if you want to make a launcher for it, here is the one that I’m using:
